AT802A

Specifications

Engine: P&W PT6A-65AG / PT6A-67AG / PT6A-67F

Horses: 1295 SHP / 1350 SHP / 1600 SHP

Helix: Hartzell HC-B5MP-3F/ M11276NS

Maximum takeoff weight: 7.257 kg (16,000 lbs)

Maximum landing weight: 7.257 kg (16,000 lbs)

Empty weight with firefighting equipment: 2.951 kg (6,505 lbs)

Payload: 4.307 kg (9,495 lbs)

Tank Capacity: 3.028 L (800 U.S. gal)

Fuel Capacity: 1.438 L (380 U.S. gal)

Scale: 18,04 m (59.2 ft)

Wing surface: 37,29 m2 (401 sq. ft)

Main Wheel Size: 81,28 cm (32.0 in)

Size tailwheel: 6.25 x 6

Approximate performance with firefighting equipment installed

Cruising speed: 307 km/h (191 mph)

Stall speed with flaps up: 172 km/h (107 mph) at 7.257 kg (16,000 lbs)

Stall speed with flaps down: 146 km/h (91 mph) at 7.257 kg (16,000 lbs)

Landing speed: 101 km/h (63 mph)

Rate of Climb: 237 mpm (780 fpm) at 7.257 kg (16,000 lbs)

Takeoff speed: 610 m (2,000 ft) at 7.257 kg (16,000 lbs)

Reach economical speed (8000 feet): 982 km (610 mi)

Notes

Confused about the 802 model designations?

The two “official” models are AT-802 (two seat cockpit) and AT-802A (single seat cockpit). Either of these aircraft can be used for agricultural work or for firefighting.

If a firefighting model 802 is equipped with the Air Tractor computerized firegate, we call it an AT-802F or AT-802AF. A model AT-802 equipped with amphibious floats is known as a Fire Boss.

AT602

Specifications

Engine: P&W PT6A-60AG

Horses: 1.050 SHP @ 1.700 RPM

Helix: Hartzell HC-B5MP-3C/M10876ANS

Maximum takeoff weight: 5.670 kg (12,500 lbs)

Maximum landing weight: 5.443 kg (12,000 lbs)

Empty weight with firefighting equipment: 2.540 kg (5,600 lbs)

Payload: 3.130 kg (6,900 lbs)

Tank Capacity: 2.385 L (630 U.S. gal)

Fuel Capacity: 817 L (216 U.S. gal)

Scale: 17,06 m (56 ft)

Wing surface: 31,24 m2 (336 sq. ft)

Main Wheel Size: 29.00 x 11

Size tailwheel: 6.25 x 6

Approximate performance with firefighting equipment installed

Cruising speed: 293 km/h (182 mph) at 2.438 m (8,000 ft)

Stall speed with flaps up: 159 km/h (99mph) at 5.670 kg (12,500 lbs)

Stall speed with flaps down: 132 km/h (82 mph) at 5.670 kg (12,500 lbs)

Landing speed: 97 km/h (60 mph)

Rate of Climb: 198 mpm (650 fpm) at 5.670 kg (12,500 lbs)

Takeoff speed: 558 m (1,830 ft) at 5.670 kg (12,500 lbs)

Reach economical speed (8000 feet): 966 km (600 mi)

AT504

Specifications

Engine: P&W PT6A-34AG

Horses: 750 SHP @ 2,200 RPM

Helix: Hartzell HC-B3TN-3D/T10282NS+4

Maximum takeoff weight: 4.354 kg (9,600 lbs)

Maximum landing weight: 3.629 kg (8,000 lbs)

Empty weight with firefighting equipment: 2.204 kg (4,860 lbs)

Payload: 2.150 kg (4,740 lbs)

Tank Capacity: 1.836 L (485 U.S. gal)

Fuel Capacity: 818 L (216 U.S. gal)

Scale: 15,84 m (52 ft)

Wing surface: 29,01 m2 (312 sq. ft)

Main Wheel Size: 29.00 x 11

Size tailwheel: 5.00 x 5

Approximate performance with firefighting equipment installed

Cruising speed: 243 km/h (151 mph) at 2.438 m (8,000 ft)

Stall speed with flaps up: 121 km/h (75 mph) at 3.629 kg (8,000 lbs)

Stall speed with flaps down: 105 km/h (65 mph) at 3.629 kg (8,000 lbs)

Landing speed: 85 km/h (53 mph)

Rate of Climb: 262 mpm (860 fpm) at 4.354 kg (9,600 lbs)

Takeoff speed: 351 m (1,150 ft) at 4.354 kg (9,600 lbs)

Reach economical speed (8000 feet): 978 km (608 mi)

AT502B

Specifications

Engine: P&W PT6A-60AG / PT6A-34AG

Horses: 1050 SHP / 750 SHP

Helix: Hartzell HC-B3TN-3D/T10282N+4

Maximum takeoff weight: 4.754 kg (10,480 lbs)

Maximum landing weight: 3.629 kg (8,000 lbs)

Empty weight with firefighting equipment: 2.073 kg (4,570 lbs)

Payload: 2.681 kg (5,910 lbs)

Tank Capacity: 1.893 L (500 U.S. gal)

Fuel Capacity: 817 L (216 U.S. gal)

Scale: 15,84 m (52 ft)

Wing surface: 29,01 m2 (312 sq. ft)

Main Wheel Size: 29.00 x 11

Size tailwheel: 5.00 x 5

Approximate performance with firefighting equipment installed

Cruising speed: 253 km/h (154 mph) at 2.438 kph (8,000 ft)

Stall speed with flaps up: 132 km/h (82 mph) at 3.629 kg (8,000 lbs)

Stall speed with flaps down: 109 km/h (68 mph) at 3.629 kg (8,000 lbs)

Landing speed: 85 km/h (53 mph)

Rate of Climb: 533 mpm (1,750 fpm) at 4.754 kg (10,480 lbs)

Takeoff speed: 244 m (800 ft) at 4.264 kg (9,400 lbs)

Reach economical speed (8000 feet): 1.127 km (700 mi)

AT402B

Specifications

Engine: P&W PT6A-15AG

Horses: 680 SHP @ 2200 RPM

Helix: Hartzell HC-B3TN-3D/T10282N+4

Maximum takeoff weight: 4.159 kg (9,170 lbs)

Maximum landing weight: 3.175 kg (7,000 lbs)

Empty weight with firefighting equipment: 1.823 kg (4,020 lbs)

Payload: 2.336 kg (5,150 lbs)

Tank Capacity: 1.514 L (400 U.S. gal)

Fuel Capacity: 644 L (170 US gal)

Scale: 15,54 m (51 ft)

Wing surface: 28,45 m2 (306 sq. ft)

Main Wheel Size: 29.00 x 11

Size tailwheel: 5.00 x 5

Approximate performance with firefighting equipment installed

Cruising speed: 261 km/h (162 mph) at 2.438 m (8,000 ft)

Stall speed with flaps up: 124 km/h (77 mph) at 3.175 kg (7,000 lbs)

Stall speed with flaps down: 106 km/h (66 mph) at 3.175 kg (7,000 lbs)

Landing speed: 85 km/h (53 mph)

Rate of Climb: 244 mpm (800 fpm) at 3.901 kg (8,600 lbs)

Takeoff speed: 297 m (975 ft) at 3.901 kg (8,600 lbs)

Reach economical speed (8000 feet): 1.062 km (660 mi)

AT401B

Specifications

Engine: P&W R1340

Horses: 600 SHP @ 2250 RPM

Helix: 12D40 hub 6101A-12 blades

Maximum takeoff weight: 3.565 kg (7,860 lbs)

Maximum landing weight: 2.722 kg (6,000 lbs)

Empty weight with firefighting equipment: 1.925 kg (4,244 lbs)

Payload: 1.640 kg (3,616 lbs)

Tank Capacity: 1.514 L (400 U.S. gal)

Fuel Capacity: 476 L (126 U.S. gal)

Scale: 15,54 m (51 ft)

Wing surface: 28,45 m2 (306 sq. ft)

Main Wheel Size: 8.50 x 10

Size tailwheel: 5.00 x 5

Approximate performance with firefighting equipment installed

Cruising speed: 230 km/h (143 mph) at 1.219 m (4,000 ft)

Stall speed with flaps up: 117 km/h (73 mph) at 2.722 kg (6,000 lbs)

Stall speed with flaps down: 98 km/h (61 mph) at 2.722 kg (6,000 lbs)

Landing speed: 87 km/h (54 mph)

Rate of Climb: 158 mpm (520 fpm) at 3.565 kg (7,860 lbs)

Takeoff speed: 402 m (1,318 ft) at 3.565 kg (7,860 lbs)

Reach economical speed (8000 feet): 1.014 km (630 mi)

AT802 Fireboss

Specifications

Engine: P&W PT6A-67AG / PT6A-67F

Horses: 1350 SHP / 1600 SHP

Helix: Hartzell HC-B5MA-3D/ M11276NS or M11691NS

Maximum takeoff weight: 7.257 kg (16,000 lbs)

Maximum landing weight: 7.257 kg (16,000 lbs)

Empty weight with firefighting equipment: 3.941 kg (8,690 lbs)

Payload: 3.316 kg (7,310 lbs)

Tank Capacity: 3.104 L (820 U.S. gal)

Fuel Capacity: 1.438 L (380 U.S. gal)

Scale: 18,04 m (59.2 ft)

Wing surface: 37,29 m2 (401 sq. ft)

Main Wheel Size: 81,28 cm (32.0 in)

Approximate performance with firefighting equipment installed

Cruising speed: 278 km/h (172 mph)

Stall speed with flaps up: 169 km/h (105 mph) at 7.257 kg (16,000 lbs)

Stall speed with flaps down: 146 km/h (91 mph) at 7.257 kg (16,000 lbs)

Landing speed: 111 km/h (69 mph)

Rate of Climb: 259 mpm (850 fpm) at 7.257 kg (16,000 lbs)

Takeoff speed: 610 m (2,000 ft) at 7.257 kg (16,000 lbs)

Reach economical speed (8000 feet): 1.287 km (800 mi)

AT802 Firefighter

Engine: P&W PT6A-67AG / PT6A-67F

Horses: 1.350 SHP / 1.600 SHP

Helix: Hartzell HC-B5MP-3F/ M11276NS or M11691NS

Maximum takeoff weight: 7.257 kg (16,000 lbs.)

Maximum landing weight: 7.257 kg (16,000 lbs.)

Empty weight with firefighting equipment: 3.198 kg (1seat); 3.270 kg (2 seats)

Payload: 4.060 kg

Tank Capacity: 3.104 L (820 U.S. gal.)

Fuel Capacity: 1.438 L (380 U.S. gal)

Scale: 18,06 m (59.25 ft.)

Wing surface: 37,29 m2 (401 sq. ft.)

Main Wheel Size: 81,28 cm (32.0 in.)

Size tailwheel: 6.25 x 6

Approximate performance with firefighting equipment installed

Cruising speed: 356 km/h (221 mph)

Stall speed with flaps up: 169 km/h (105 mph)

Stall speed with flaps down: 146 km/h (91 mph)

Landing speed: 111 km/h (69 mph)

Rate of Climb: 259 mpm (850 fpm) at 7.257 kg (16,000 lbs)

Takeoff speed: 610 m (2,000 ft.) at 7.257 kg (16,000 lbs.)

Reach economical speed (8000 feet): 1.287 km (800 mi)

Notes

Confused about the 802 model designations?

The two “official” models are AT-802 (two seat cockpit) and AT-802A (single seat cockpit). Either of these aircraft can be used for agricultural work or for firefighting.

If a firefighting model 802 is equipped with the Air Tractor computerized firegate, we call it an AT-802F or AT-802AF. A model AT-802 equipped with amphibious floats is known as a Fire Boss.

AT802A

Motor: P&W PT6A-65AG / PT6A-67AG / PT6A-67F

Caballos: 1295 SHP / 1350 SHP / 1600 SHP

Hélice: Hartzell HC-B5MP-3F/ M11276NS

Peso máximo al despegue: 7.257 kg (16,000 lbs)

Peso máximo al aterrizaje: 7.257 kg (16,000 lbs)

Peso en vacío con equipo de fumigación: 2.951 kg (6,505 lbs)

Carga útil: 4.307 kg (9,495 lbs)

Capacidad del depósito: 3.028 L (800 U.S. gal)

Capacidad de combustible: 1.438 L (380 U.S. gal)

Envergadura: 18,04 m (59.2 ft)

Superficie de ala: 37,29 m2 (401 sq. ft)

Tamaño de rueda principal: 81,28 cm (32.0 in)

Tamaño de rueda de cola: 6.25 x 6

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 307 km/h (191 mph)

Velocidad de pérdida con los flaps arriba: 172 km/h (107 mph) at 7.257 kg (16,000 lbs)

Velocidad de pérdida con los flaps abajo: 146 km/h (91 mph) at 7.257 kg (16,000 lbs)

Velocidad de aterrizaje: 101 km/h (63 mph)

Velocidad de ascenso: 237 mpm (780 fpm) at 7.257 kg (16,000 lbs)

Velocidad de despegue: 610 m (2,000 ft) at 7.257 kg (16,000 lbs)

Alcance a velocidad económica (8000 pies): 982 km (610 mi)

AT602

Motor: P&W PT6A-60AG

Caballos: 1.050 SHP @ 1.700 RPM

Hélice: Hartzell HC-B5MP-3C/M10876ANS

Peso máximo al despegue: 5.670 kg (12,500 lbs)

Peso máximo al aterrizaje: 5.443 kg (12,000 lbs)

Peso en vacío con equipo de fumigación: 2.540 kg (5,600 lbs)

Carga útil: 3.130 kg (6,900 lbs)

Capacidad del depósito: 2.385 L (630 U.S. gal)

Capacidad de combustible: 817 L (216 U.S. gal)

Envergadura: 17,06 m (56 ft)

Superficie de ala: 31,24 m2 (336 sq. ft)

Tamaño de rueda principal: 29.00 x 11

Tamaño de rueda de cola: 6.25 x 6

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 293 km/h (182 mph) at 2.438 m (8,000 ft)

Velocidad de pérdida con los flaps arriba: 159 km/h (99mph) at 5.670 kg (12,500 lbs)

Velocidad de pérdida con los flaps abajo: 132 km/h (82 mph) at 5.670 kg (12,500 lbs)

Velocidad de aterrizaje: 97 km/h (60 mph)

Velocidad de ascenso: 198 mpm (650 fpm) at 5.670 kg (12,500 lbs)

Velocidad de despegue: 558 m (1,830 ft) at 5.670 kg (12,500 lbs)

Alcance a velocidad económica (8000 pies): 966 km (600 mi)

AT504

Motor: P&W PT6A-34AG

Caballos: 750 SHP @ 2,200 RPM

Hélice: Hartzell HC-B3TN-3D/T10282NS+4

Peso máximo al despegue: 4.354 kg (9,600 lbs)

Peso máximo al aterrizaje: 3.629 kg (8,000 lbs)

Peso en vacío con equipo de fumigación: 2.204 kg (4,860 lbs)

Carga útil: 2.150 kg (4,740 lbs)

Capacidad del depósito: 1.836 L (485 U.S. gal)

Capacidad de combustible: 818 L (216 U.S. gal)

Envergadura: 15,84 m (52 ft)

Superficie de ala: 29,01 m2 (312 sq. ft)

Tamaño de rueda principal: 29.00 x 11

Tamaño de rueda de cola: 5.00 x 5

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 243 km/h (151 mph) at 2.438 m (8,000 ft)

Velocidad de pérdida con los flaps arriba: 121 km/h (75 mph) at 3.629 kg (8,000 lbs)

Velocidad de pérdida con los flaps abajo: 105 km/h (65 mph) at 3.629 kg (8,000 lbs)

Velocidad de aterrizaje: 85 km/h (53 mph)

Velocidad de ascenso: 262 mpm (860 fpm) at 4.354 kg (9,600 lbs)

Velocidad de despegue: 351 m (1,150 ft) at 4.354 kg (9,600 lbs)

Alcance a velocidad económica (8000 pies): 978 km (608 mi)

AT502B

Motor: P&W PT6A-60AG / PT6A-34AG

Caballos: 1050 SHP / 750 SHP

Hélice: Hartzell HC-B3TN-3D/T10282N+4

Peso máximo al despegue: 4.754 kg (10,480 lbs)

Peso máximo al aterrizaje: 3.629 kg (8,000 lbs)

Peso en vacío con equipo de fumigación: 2.073 kg (4,570 lbs)

Carga útil: 2.681 kg (5,910 lbs)

Capacidad del depósito: 1.893 L (500 U.S. gal)

Capacidad de combustible: 817 L (216 U.S. gal)

Envergadura: 15,84 m (52 ft)

Superficie de ala: 29,01 m2 (312 sq. ft)

Tamaño de rueda principal: 29.00 x 11

Tamaño de rueda de cola: 5.00 x 5

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 253 km/h (154 mph) at 2.438 kph (8,000 ft)

Velocidad de pérdida con los flaps arriba: 132 km/h (82 mph) at 3.629 kg (8,000 lbs)

Velocidad de pérdida con los flaps abajo: 109 km/h (68 mph) at 3.629 kg (8,000 lbs)

Velocidad de aterrizaje: 85 km/h (53 mph)

Velocidad de ascenso: 533 mpm (1,750 fpm) at 4.754 kg (10,480 lbs)

Velocidad de despegue: 244 m (800 ft) at 4.264 kg (9,400 lbs)

Alcance a velocidad económica (8000 pies): 1.127 km (700 mi)

AT402B

Motor: P&W PT6A-15AG

Caballos: 680 SHP @ 2200 RPM

Hélice: Hartzell HC-B3TN-3D/T10282N+4

Peso máximo al despegue: 4.159 kg (9,170 lbs)

Peso máximo al aterrizaje: 3.175 kg (7,000 lbs)

Peso en vacío con equipo de fumigación: 1.823 kg (4,020 lbs)

Carga útil: 2.336 kg (5,150 lbs)

Capacidad del depósito: 1.514 L (400 U.S. gal)

Capacidad de combustible: 644 L (170 US gal)

Envergadura: 15,54 m (51 ft)

Superficie de ala: 28,45 m2 (306 sq. ft)

Tamaño de rueda principal: 29.00 x 11

Tamaño de rueda de cola: 5.00 x 5

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 261 km/h (162 mph) at 2.438 m (8,000 ft)

Velocidad de pérdida con los flaps arriba: 124 km/h (77 mph) at 3.175 kg (7,000 lbs)

Velocidad de pérdida con los flaps abajo: 106 km/h (66 mph) at 3.175 kg (7,000 lbs)

Velocidad de aterrizaje: 85 km/h (53 mph)

Velocidad de ascenso: 244 mpm (800 fpm) at 3.901 kg (8,600 lbs)

Velocidad de despegue: 297 m (975 ft) at 3.901 kg (8,600 lbs)

Alcance a velocidad económica (8000 pies): 1.062 km (660 mi)

AT401B

Motor: P&W R1340

Caballos: 600 SHP @ 2250 RPM

Hélice: 12D40 hub 6101A-12 blades

Peso máximo al despegue: 3.565 kg (7,860 lbs)

Peso máximo al aterrizaje: 2.722 kg (6,000 lbs)

Peso en vacío con equipo de fumigación: 1.925 kg (4,244 lbs)

Carga útil: 1.640 kg (3,616 lbs)

Capacidad del depósito: 1.514 L (400 U.S. gal)

Capacidad de combustible: 476 L (126 U.S. gal)

Envergadura: 15,54 m (51 ft)

Superficie de ala: 28,45 m2 (306 sq. ft)

Tamaño de rueda principal: 8.50 x 10

Tamaño de rueda de cola: 5.00 x 5

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 230 km/h (143 mph) at 1.219 m (4,000 ft)

Velocidad de pérdida con los flaps arriba: 117 km/h (73 mph) at 2.722 kg (6,000 lbs)

Velocidad de pérdida con los flaps abajo: 98 km/h (61 mph) at 2.722 kg (6,000 lbs)

Velocidad de aterrizaje: 87 km/h (54 mph)

Velocidad de ascenso: 158 mpm (520 fpm) at 3.565 kg (7,860 lbs)

Velocidad de despegue: 402 m (1,318 ft) at 3.565 kg (7,860 lbs)

Alcance a velocidad económica (8000 pies): 1.014 km (630 mi)

AT802 Fireboss

Motor: P&W PT6A-67AG / PT6A-67F

Caballos: 1350 SHP / 1600 SHP

Hélice: Hartzell HC-B5MA-3D/ M11276NS or M11691NS

Peso máximo al despegue: 7.257 kg (16,000 lbs)

Peso máximo al aterrizaje: 7.257 kg (16,000 lbs)

Peso en vacío con equipo de fumigación: 3.941 kg (8,690 lbs)

Carga útil: 3.316 kg (7,310 lbs)

Capacidad del depósito: 3.104 L (820 U.S. gal)

Capacidad de combustible: 1.438 L (380 U.S. gal)

Envergadura: 18,04 m (59.2 ft)

Superficie de ala: 37,29 m2 (401 sq. ft)

Tamaño de rueda principal: 81,28 cm (32.0 in)

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 278 km/h (172 mph)

Velocidad de pérdida con los flaps arriba: 169 km/h (105 mph) at 7.257 kg (16,000 lbs)

Velocidad de pérdida con los flaps abajo: 146 km/h (91 mph) at 7.257 kg (16,000 lbs)

Velocidad de aterrizaje: 111 km/h (69 mph)

Velocidad de ascenso: 259 mpm (850 fpm) at 7.257 kg (16,000 lbs)

Velocidad de despegue: 610 m (2,000 ft) at 7.257 kg (16,000 lbs)

Alcance a velocidad económica (8000 pies): 1.287 km (800 mi)

AT802 Firefighter

Motor: P&W PT6A-67AG / PT6A-67F

Caballos: 1.350 SHP / 1.600 SHP

Hélice: Hartzell HC-B5MP-3F/ M11276NS or M11691NS

Peso máximo al despegue: 7.257 kg (16,000 lbs.)

Peso máximo al aterrizaje: 7.257 kg (16,000 lbs.)

Peso en vacío con equipo de fumigación: 3.198 kg (1seat); 3.270 kg (2 seats)

Carga útil: 4.060 kg

Capacidad del depósito: 3.104 L (820 U.S. gal.)

Capacidad de combustible: 1.438 L (380 U.S. gal)

Envergadura: 18,06 m (59.25 ft.)

Superficie de ala: 37,29 m2 (401 sq. ft.)

Tamaño de rueda principal: 81,28 cm (32.0 in.)

Tamaño de rueda de cola: 6.25 x 6

Prestaciones aproximadas con equipo de fumigación instalado

Velocidad de crucero: 356 km/h (221 mph)

Velocidad de pérdida con los flaps arriba: 169 km/h (105 mph)

Velocidad de pérdida con los flaps abajo: 146 km/h (91 mph)

Velocidad de aterrizaje: 111 km/h (69 mph)

Velocidad de ascenso: 259 mpm (850 fpm) at 7.257 kg (16,000 lbs)

Velocidad de despegue: 610 m (2,000 ft.) at 7.257 kg (16,000 lbs.)

Alcance a velocidad económica (8000 pies): 1.287 km (800 mi)
